GT-Rabbit R249HD 2inch

Diatone 2019 GT R249 HD Edition 2 Inch 4S FPV Racing RC Drone PNP RunCam Split Mini 2 TX200 F4 OSD

39
Diatone innovations 2019 GT-Rabbit R249HD 2inch
GT-Rabbit R249HD

GT-Rabbit R249HD

by Diatone innovations 2019

Cinewhoop

Specification:
Brand name: Diatone
Item name: GT-Rabbit  R249(R90) 2inch 3-4S
Color: Bla/White/Transparent
Fury F4 OSD 8K flight controller: MPU6000 Six-Axis; OSD; 16M Flash; 5V 2A BEC;
Camera: RunCam Split Mini 2
VTX: Runcam TX200U VTX

Model RunCam TX200U
Frequency Channel 5.8G 48CH
Output Power 25mW / 200mW
Working Current 5V@150~400mA
Voltage out 5V@max 250mA
Voltage in 1S 3.5-5.5V
Video Input Impedance 75 Ohm
Antenna U.FL 5.8G 2dB Omni antenna
Weight 2.5g (with antenna)
PCB Size 19mm*19mm

ESC: F25 20A Current Sensor 3-4S
Motor: Mamba racing 1105 5500KV 3-4S
Propeller: 2 inch
